| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZISA |
| Certification: | CE |
| Model Number: | G2500 |
| Minimum Order Quantity: | 1 |
| Price: | 145-240USD |
| Packaging Details: | box 1kg |
| Delivery Time: | 5-8weeks |
| Payment Terms: | T/T |
| Supply Ability: | 10000PCS |
| Product Name: | SHDSL.BIS Bridge | Port: | 1*DSL+4 FE |
|---|---|---|---|
| WIFI: | NONE | Color: | Gray |
| Type: | SHDSL Bridge | Power Supply: | DC 12V 1A |
| Certification: | CE | Chipset: | NONE |
| High Light: | 12v 1a modem shdsl,four ethernet lan modem shdsl,12v 1a shdsl modem |
||
G shdsl bis Router modem with four Ethernet LAN 2 wire 5.7 to 15M
|
|
| Loopbacks: |
Local and remote AL/DL loopbacks via front panel loopback buttons, VT-100 menu screen or in-band loopback codes |
| DSL PRBS BER testing | |
| SNR, LOSW, ES, SES and UAS for DSL loops | |
| Supports G.821 and G.826 error performance statistics for E1 interfaces | |
|
|
| Optional LCD display: | Quick mode configuration, diagnostics and monitoring |
|
Optional SNMP/Telnet |
Telnet access and an optional SNMP agent support. Web management is optional |
Meets G.823 and G.824 jitter and wander requirements for E1 interface
DC: -36 ~ -72 VDC
AC: 90 ~ 260V AC (47 ~ 63 Hz)
AC and/or DC power source can be field selectable. The AC and DC power inputs can be served as power protection mutually.
Enclosure:234.4mm x 155.5mm x 44.2 mm (WxLxH)
Temperature: 0 ~ 60 degree C
Humidity: Up to 95% non-condensing
EN 55022 and 55024 compliant
Safety: EN60950 compliant
Surge immunity: L1:L2 1KV , L1/L2:PE 2KV
Lighting Surge : 4KV
Ordering Information
| G2100 series | Management | ||||||
| Model | DSL | Mode*1 | Data Interface*2 | ETH ERNET*3 | PANEL | NET | |
| G2100 | 2W/4W | □TDM □DualBearer | □E1□E1+COD□V.35□E1+V.35 | □LAN | □LAN*4 | LCD | HTTP+SNMP |
option
Features
FAQ
Q1. ZISA product the quality of products.
A: As the top class total solution provider and productive service provider, we provide high quality of service to Tier1 Telco customer and Vendors. With the genius design and software customization expertise, we can leverage the best service to our customers. ZISA Product quality is same as Huawei and ZTE, and ZISA has complete product line.
Flexible , Smart and selective producing system, the top manufacture in vertical career choose our team, with decade of global market and professional experience.
Q2. ZISA after-sales service.
A:ZISA has complete software and hardware research and development. Provide reqiurment development, bug modify and 24h on-line support. For significant customers, ZISA can send technician to support.
Q3. Ways of cooperation with ZISA.
A :ZISA welcome integrator or agent to agent ZISA product. If agent has enough advantages in the market, ZISA appoint you ZISA sole agent.
Q4. About factory visit.
A :ZISA welcome significant customers to visit ZISA factory. Please make an appointment in two weeks.
Q5. About product pricing.
A :ZISA only publish sample price. The price of different agent and OEM customer is secret. ZISA gives specific price for significant projects and customers. Besides, ZISA only provide goods to agent in agent area.
