| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZISA |
| Certification: | CE |
| Model Number: | G2500 |
| Minimum Order Quantity: | 1 |
| Price: | 145-240USD |
| Packaging Details: | box 1kg |
| Delivery Time: | 5-8weeks |
| Payment Terms: | T/T |
| Supply Ability: | 10000PCS |
| Product Name: | ATM/EFM Bridge | Management: | WEB |
|---|---|---|---|
| Housing: | Plastic Case | Storage Humidity: | 5%—95%, Non-condensing |
| Power Supply: | 12V 1A | Certification: | CE |
| Chipset: | NONE | Color: | Gray |
| High Light: | WEB TELNET SHDSL MODEM,SHDSL MODEM 4x 10/100 LAN,G.SHDSL.BIS 11b/g/n firewall router |
||
WEB TELNET Modem G.SHDSL.BIS 11b/g/n Router 4x 10/100 LAN Ports G2500
Company Profile:
ZISA Technology Limited was created in 2004, based in Beijing.
We are an innovative ICT company for more than 10 years.
ZISA is committed to providing the professional service and solutions to oversea customers, making continuous innovation to meet the requirements of customers.As a global market company, ZISA Fibre PON equipment, wireless AP solutions and xDSL solutions have been reached over 30 countries and regions.
Software
ATM Protocol
VC multiplexing and LLC encapsulation
Multi-protocol over AAL5 (RFC 1483/2684 bridged and routed PDU)
Classical IP over ATM (RFC 1577 with MTU = 1500)
4 PVCs
ATM QoS CBR, UBR, VBR, VBR-rt support
UNI 3.1/4.0 PVC
I.610 OAM F5 loopback
PPP Support
PPP (RFC 1661)
PPP over Ethernet (RFC 2516)
User authentication with PAP/CHAP
PPTP and L2TP ( VPN )
Routing Capability
Support IP/TCP/UDP/ARP/ICMP protocols
IP routing with static routing and RIPv2 (RFC1058/2453), OSPF( RFC1583 ), BGP
Network address translation (NAT/PAT) (RFC1631), one to one, many to one, many to many
DNS relay and caching (RFC1034/1035)
DHCP server (RFC2131/2132)
Support IP / MAC / DNS Filter
Support DDNS function
Bridging
IEEE 802.1D transparent learning bridge
Up to 2048 MAC learning addresses
Raid spanning tree ( 802.3w )
Configuration
Local console (RS232)
Telnet access
Web-based GUI (HTTP)
Network Management
Web-based GUI for express setup, configuration and management
Local console and Telnet access, command line and configure for sub-interfaces.
Password protected management and access control list for administration
SNMP management with SNMPv1/SNMPv2c
Software upgrade via TFTP server
Supports inband management vlan.
Ordering Information
G2502 ---- single pairs, up to 15Mbps
G2504 ---- two pairs, up to 30Mbps
G2508 ---- four pairs, up to 60Mbps
Hardware
| Power Supply | External power adapter 12V DC, 1000mA |
| LAN Port | RJ45 x 4 |
| WAN Port | RJ11 x 2 |
| Console Port | RJ45 x 1 |
| Operating temperature | 0° to 45°C |
| Storage temperature | -10° to 70°C |
| Housing | plastic case |
| Dimension | 220mm x 150mm x 40mm (L x W x H) |
