| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZISA |
| Certification: | CE |
| Model Number: | MA5616 |
| Minimum Order Quantity: | 1 |
| Price: | 265-2400USD |
| Packaging Details: | box 14kg |
| Delivery Time: | 1weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100pcs |
| Product Name: | GPON DSLAM | Type: | GPON/EPON |
|---|---|---|---|
| Port: | 64 Adsl Port | Warranty: | 1 YEAR |
| High: | 2U | Certification: | CE |
| Operating Temperature: | -40℃ To 65℃; Startup At -25℃ | Management: | Telnet And CLI |
| High Light: | 48 channel huawei 5616,huawei 5616 adsl2,vectoring huawei smartax ma5616 |
||
ZISA Huawei SmartAX Mini DSLAM MA5616 with 48-channel ADSL2 support vectoring
The SmartAX MA5616 (the MA5616 for short) is an industry-leading remote multi dwelling unit (MDU) launched by Huawei, which supports flexible configurations and provides broadband services on Fiber To The Building (FTTB) and Fiber To The Curb (FTTC) networks. The MA5616 is a box-type device measuring 2-U high and 19-inch wide and providing two GPON or GE uplink ports and ADSL2+,VDSL2, SHDSL, POTS, ISDN, FE and GE ports. The MA5616 features a high access density, high processing capability, high reliability, easy maintenance, environment-friendlily and energy conservation, and future-oriented architecture design and can be used in corridors, cabinets, indoor, and outdoor usage scenarios.
Specifications
| Features | CCUB control board | CCUC control board |
| Dimensions (H×W×D) | 88.1mm × 442mm × 245mm | 88.1mm × 442mm × 245mm |
| Network-side port | The MA5616 supports the following configurations: • 1 × GPON + 1 × GE • 2 × GE |
The MA5616 supports the following configurations: • 1 × GPON + 1 × GE • 2 × GE |
| User-side port | The MA5616 provides four slots and the following 10 service boards: • 24-channel VDSL2 board (17a, over POTS, built-in SPL) • 24-channel VDSL2 board (17a, over POTS, external SPL) • 24-channel VDSL2 board (17a, over ISDN, external SPL) • 16-channel VDSL2 board (30a, over POTS, built-in SPL) • 32-channel ADSL2+ board (built-in SPL) • 32-channel combo board (32 × POTS + 32 × ADSL2+) • 64-channel POTS board • 32-channel POTS board • 8-channel ISDN board • 16-channel G.SHDSL board (supporting ATM and PTM) |
The MA5616 provides four slots and the following 13 service boards: • 24-channel VDSL2 board (17a, over POTS, built-in SPL) • 24-channel VDSL2 board (17a, over POTS, external SPL) • 24-channel VDSL2 board (17a, over ISDN, external SPL) • 16-channel VDSL2 board (30a, over POTS, built-in SPL) • 32-channel ADSL2+ board (built-in SPL) • 32-channel combo board (32 × POTS + 32 × ADSL2+) • 64-channel POTS board • 32-channel POTS board • 8-channel ISDN board • 16-channel G.SHDSL board (supporting ATM and PTM) • 16-channel FE (electrical) board • P2P board with 4 GE (combo of optical port and electrical port) + 4 FE (optical port) • 48-channel VDSL2 board (17a, over POTS, external SPL, supporting MELT) |
| Operating temperature | -40℃ to 65℃; startup at -25℃ | -40℃ to 65℃; startup at -25℃ |
| Humidity | 5% to 95% (non-condensing) | 5% to 95% (non-condensing) |
| Heat dissipation mode | Providing fans for heat dissipation. The rotating speed can be automatically adjusted. | Providing fans for heat dissipation. The rotating speed can be automatically adjusted. |
| Power supply | AC: 220 V/110 V DC: -48 V |
AC: 220 V/110 V DC: -48 V |
| Backup power | Support for 48-V backup power Support for lead-acid batteries and LiFePO4 batteries | Support for 48-V backup power Support for lead-acid batteries and LiFePO4 batteries |
| Weight | 4.8 kg (empty chassis) 7.2 kg (full configuration) |
4.8 kg (empty chassis) 7.2 kg (full configuration) |
