2U CCUE Control Board SHLH MDU IP SHDSL DSLAM Smartax MA5616 Chassis

Basic Information
Place of Origin: CHINA
Brand Name: ZISA
Certification: CE
Model Number: MA5616
Minimum Order Quantity: 1
Price: 265-2400USD
Packaging Details: box 14kg
Delivery Time: 1weeks
Payment Terms: T/T
Supply Ability: 100pcs
Detail Information
Product Name: MDU IP DSLAM SHDSL TYPE: SHDSL
Port: SHDSL Warranty: 1 YEAR
High: 2U Certification: CE
Operating Temperature: -40℃ To 65℃; Startup At -25℃ Management: Telnet And CLI
High Light:

SHLH MDU SHDSL DSLAM

,

SHDSL DSLAM Smartax MA5616 Chassis

,

Smartax MA5616 Chassis


Product Description

2U CCUE Control board SHDSL SHLH MDU IP DSLAM Smartax MA5616 Chassis



Characteristics



High access density: The MA5616 supports a maximum of 256 POTS users, 128 ADSL2+ users, 192 VDSL2 users, or 64FE users. The MA5616 supports 128 POTS users and 128 ADSL2+ users simultaneously by using a combo board.

Flexible configurations: Service boards are slot compatible and different types of ports can be configured flexibly, improving the actual configuration ratio and meeting different customer requirements.

Support for the combo board to improve the access density, reduce the space of the equipment room, and simplify cable routing complexity.

Support for the P2P optical access board (4GE+4FE) to provide high bandwidth for valued customers.

Support for 48-V backup power (lead-acid batteries and LiFePO4 batteries).



Features



Dimensions (H×W×D) 88.1mm × 442mm × 245mm
Network-side port The MA5616 supports the following configurations:
• 1 × GPON + 1 × GE
• 2 × GE
User-side port The MA5616 provides four slots and the following 10 service boards:
• 24-channel VDSL2 board (17a, over POTS, built-in SPL)
• 24-channel VDSL2 board (17a, over POTS, external SPL)
• 24-channel VDSL2 board (17a, over ISDN, external SPL)
• 16-channel VDSL2 board (30a, over POTS, built-in SPL)
• 32-channel ADSL2+ board (built-in SPL)
• 32-channel combo board (32 × POTS + 32 × ADSL2+)
• 64-channel POTS board
• 32-channel POTS board
• 8-channel ISDN board
• 16-channel G.SHDSL board (supporting ATM and PTM)



FAQ



Q1. ZISA product the quality of products.
A: As the top class total solution provider and productive service provider, we provide high quality of service to Tier1 Telco customer and Vendors. With the genius design and software customization expertise, we can leverage the best service to our customers. ZISA Product quality is same as Huawei and ZTE, and ZISA has complete product line.

Flexible , Smart and selective producing system, the top manufacture in vertical career choose our team, with decade of global market and professional experience.



Q2. ZISA after-sales service.
A:ZISA has complete software and hardware research and development. Provide reqiurment development, bug modify and 24h on-line support. For significant customers, ZISA can send technician to support.

Q3. Ways of cooperation with ZISA.
A :ZISA welcome integrator or agent to agent ZISA product. If agent has enough advantages in the market, ZISA appoint you ZISA sole agent.

Q4. About factory visit.
A :ZISA welcome significant customers to visit ZISA factory. Please make an appointment in two weeks.

Q5. About product pricing.
A :ZISA only publish sample price. The price of different agent and OEM customer is secret. ZISA gives specific price for significant projects and customers. Besides, ZISA only provide goods to agent in agent area.
