White 1x8 PLC Splitter Lgx Box 1260 nm To 1650nm Operating Wavelength

Basic Information
Place of Origin: China
Brand Name: Qualfiber/OEM
Model Number: PLC LGX
Minimum Order Quantity: 1 Piece/Pieces
Price: $6.00 - $10.00 / Pieces
Packaging Details: blister box
Supply Ability: 20000 Piece/Pieces per Month
Contact Now
Type: LGX BOX Compliance: Telcordia GR-1209-CORE-2001 & Telcordia GR-1221-CORE-1999
Color: White Insertion Loss (dB): 13.5
Return Loss (dB): 55 Polarization Dependent Loss(dB): 0.2
Fiber Channel: 1x8 Operating Wavelength: 1260nm To 1650nm
Operating Temperature: -40℃ To 85℃ Temperature Stability(-40~85 ℃)(dB): 0.5
Port: Shenzhen

Features

Low insertion loss, low PDL

Good channel to channel uniformity
Wide operating wavelength from 1260-1650nm

Compact design
Plugging and unplugging conveniently by means of patch cords with patch latch



Application

CATV system
Optical fiber sensor
LAN network
FTTH



Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements.



Features

        Low Insertion loss

        Low PDL

        Compact Design

        Good channel-to-channel uniformity

        Wide Operating Wavelength:

       From 1260nm to 1650nm

        Wide Operating Temperature:

       From -40 to 85

        High Reliability and Stability



Applications

        FTTX Systems

        PON Networks

        CATV Links

        Optical Signal Distribution

Compliance

         Telcordia GR-1209-CORE-2001

         Telcordia GR-1221-CORE-1999

        RoHS

Specifications

Table 1 – 1×N PLC Splitter

Parameters

  1x2

1×4

1×8

1×16

1×32

1×64

1×128

Operating Wavelength (nm)

 1260~1650

Fiber Type

G657A or customer specified

Insertion Loss (dB)

 3.8

 7.0

 10.2

13.5

16.8

20.5

24.5

Loss Uniformity (dB)

0.4

0.5

0.8

1.0

1.2

2

2.5

Return Loss (dB)

55

55

55

55

55

55

55

Polarization Dependent Loss(dB)

0.2

0.2

0.2

0.2

0.2

0.35

0.35

Directivity (dB)

55

55

55

55

55

55

55

Wavelength Dependent Loss(dB)

0.3

0.3

0.3

0.5

0.5

0.5

0.5

Temperature Stability(-40~85 )(dB)

0.4

0.4

0.4

0.5

0.5

0.5

0.5

Operating Temperature ()

-5~75

Storage Temperature ()

-40~85

Device Dimension (mm)   (L×W×H)

40×4×4

40×4×4

40×4×4

50×4×4

60×7×4

60×12×4

NA

Module Dimension (mm)   (L×W×H)

100×80×10

100×80×10

130×112×30

120×80×18

140×115×18

140×115×18

140×115×18

Mini-Module Dimension (mm)   (L×W×H)

60×7×4

60×7×4

60×7×4

60×12×4

80×20×6

100X40X6

NA

Notes:

1.     Specified without connectors.

2.     Add an additional 0.2dB loss per connector.



Notes:

1, Specified without connectors.

2, Add an additional 0.2dB loss per connector.
